Basic Info.:
Material:Metal base+PMMA diffuser
Wattage:18W
Total Lumen:1800lm
Power Supply:AC 220-240V 50/60Hz
AC 100-127V 50/60Hz
Finishing: White
IP Rating: IP20/ IP44
Warranty: 3Yrs
Certificates:CE / SAA / RoHs / Erp
Energy Class: A class
| Model | Power | Luminous | Dimension |
| L3318CCT | 18W | 1800LM | Φ330mm x H 75mm |
| L3824CCT | 24W | 2350LM | Φ380mm x H 85mm |
| L4832CCT | 32W | 3100LM | Φ480mm x H 105mm |
| L5943CCT | 43W | 4100LM | Φ590mm x H 105mm |
Its installation and commissioning can be easily mastered by everyone.
1. It is important to turn off the power first before installation!
2. Drill holes, then insert the supplied dowels into the holes. Take off the lamp cover, then fasten the lamp to the ceiling with the screws also included.
3. Connect the wires through the terminal block (see user manual diagram), then you can turn the power back on and put the hood back on!
Check and clean the ceiling lamp every six months! During cleaning, wipe the hood first with a damp, soft cloth, then with a dry cloth, avoiding the electrical parts! Do not wipe with ethanol or gasoline!
The manufacturer provides a 3-year warranty for the product!
For indoor use only!
